Printing System
| Dye sublimation re-transfer |
| Printing density 300dpi x 300dpi |
Printing Overview
| Single sided printing |
| Full color 256 gradations - Dye-sublimation printing |
| Text, numeric, logo’s 1D, 2D bar code |
Card Personalization Speed
| YMCK (single-sided) | 30 sec/card, 120 cards/hour |
| YMCKK (double-sided) | 56 sec/card, 64 cards/hour |
Printer Overview
| Card hopper | 100 cards |
| Card output hopper | 100 Cards |
| Optional card hopper | 250 Cards |
| Cards thickness | 0.25mm ~ 1.00mm Size: 54.0mm * 85.6mm |
Dimensions, Weight, & Operating Environment
| Dimensions | 343mm * 335mm * 322mm (W*H*D) (without card stacker) |
| Mass approx. | Single side 13.5kg Dual side 13.7kg |
| Temperature | 15°C to 30°C Humidity: 35% to 70% (YMCK ink, No condensation) |
Safety Standards
| UL,CE,FCC,KC,CCC,CSA,BIS |
Operating Systems and Security Features
| Microsoft® Windows®11 32bit/64bit |
| Microsoft® Windows®10 32bit/64bit |
| Microsoft® Windows®8 (including 8.1) 32bit/64bit |
| Microsoft® Windows®7 (SP1) 32bit/64bit |
| Microsoft® Windows® Server 2012 64Bit |
| Microsoft® Windows® Server 2008 R2 (SP1) 64Bit |
| Interface USB2.0 (Hi-speed / Full Speed) |
| Ethernet (100BASE-TX / 10BASE-T) |
| Electronic locking system for input hopper, colour ribbon and INTM Film |
Software Development Kit
| K-Series optional SDK (Contact your local sales office) |
Encoding Options
| Magnetic stripe encoder (K30D only) |
| Smart card contact/contactless |
Warranty
| 36 months printer warranty with lifetime on Printhead |
Included with the Printer
| Power cord with power supply |
| USB / Ethernet cable |
| Cleaning card |
| Printer driver CD |
| Quick install guide |
| Bend Remedy |
